4.5.1.2 Change Component Name
This command changes the specified component name stored in the Component data.
Screen Function
PWB data
Basic setting screen
This command cannot be used.
Dimension setup screen
Circuit Layout screen
Ex. Bad Mark screen
PWB Conveyor screen
Placement data
List screen You can change a component name.
Area Mark screen
This command cannot be used.
Area Bad Mark screen
Component data
List screen
You can change a component name.
Form screen
Pick data
List screen
Form screen
The system changes a component name only, and any other data does not change.
A component name specified before changing is displayed in the “Component Name: from” area.
A component name specified before changing is highlighted in the “To” edit box.
Enter a new name in this “To” edit box.
When you press the <OK> button, the component name is changed to the new name you entered.
When you press the <Cancel> button, the component name does not change, and the previous
screen reappears.
If the entered new name is already used in another component, the dialog box like one shown
below appears on the screen.
Part 1 Basic Operation Chapter 4 Creating a Production Program
4-157
4.5.1.3 Update layers
This command incorporates a layer specified in the Component data into the Placement data.
The system incorporates a layer in the following two ways.
All component: The system incorporates layers specified in all component data records
into the Placement data.
Current component: The system incorporates a layer of the specified component into the
Placement data.
Screen Function
PWB data
Basic setting screen
This command cannot be used.s
Dimension setup screen
Circuit Layout screen
Ex. Bad Mark screen
PWB Conveyor screen
Placement data
List screen
When all Component data is created
completely, you can select the <All> button.
Area Mark screen
This command cannot be used.
Area Bad Mark screen
Component data
List screen
Form screen
When the corresponding component data is
created completely, you can select the <Current
component> button.
Pick data
List screen
Form screen
Form screen
4.5.1.4 Update pick offset
This command uses the “Pick position” set on the “Pick” data screen to specify the “Picking offset”
on the “Component” data screen.
When you select one data record on the “Pick” data screen and the [Update pick offset] command
after data editing operation such as teaching, the difference between the default pick-up value of
the selected “Pick” data record and the input value can be used for the “Picking offset” on the
“Component” data screen.
Screen
Description
PWB data
“Basic setting” screen
This command cannot be used.
“Dimension setup” screen
“Circuit Layout” screen
“Ex. Bad Mark” screen
“PWB Conveyor” screen
Placement data
“List” screen
This command cannot be used.
“Area Mark” screen
“Area Bad Mark” screen
Component data
“List” screen
This command cannot be used.
“Form” screen
Pick data
“List” screen
This command can be used when you
select the menu item “XYZ.”
“Form” screen
This command cannot be used.
