Glossary
A−9
S-VCS
An abbreviation for Scanning Vision Centering System. This system centers a component
with a VCS while moving a head that has picked up a component above the VCS in the X
direction to control recognition of a component with its image.
This can recognize a component faster than the conventional image recognition devices.
Teaching
Teaching is to acquire coordinates using an HOD, also using OCC, head etc., and basically, it
is broadly divided into two types of teaching.
One is Teaching of coordinates, which means to acquire the location of specific unit's position
(placement position etc.) using an OCC etc. and make the machine learn the data.
The other is Teaching of recognition, which mainly performs BOC mark and IC mark's shape,
size, and contrast adjustment and setting of detection area and others using an OCC etc. in the
same manner in order to teach the machine.
For both of the above, the information of the coordinates and marks acquired by teaching will
be reflected in the production program.
Tray holder
A tray holder is equipment to supply tray components, and this item is supplied at customer's
option. A holder is used in production by attaching the holder to the feeder bank on the rear,
and putting tray components together with the tray on the holder. The program allows
maximum 20 types of trays to be attached to the holder.
VCS (unit)
This unit recognizes the shape of an electronic component (with leads or balls) and measures
the retaining posture.
The other system is Image centering, which is also called vision centering or VCS centering.
This centering system allows the mounter to inspect and place on a board a component whose
lead pitch is less than 0.65 mm (such a component cannot be centered with laser) by using the
dedicated camera.
The camera used in this operation is called a VCS camera. It is used mainly in centering of
QFP, PLCC, connector, BGA etc. and pitch, lead bend, lead length, ball deformation inspection
etc., for which laser is not effective, can be seen.
Further, use of the optional VCS camera (0.3 mm VCS) can perform centering placement of
those components with smaller lead pitch (lead pitch of 0.3 to 0.4 mm), where this is an option
to be set at the factory. This centering is similar to laser centering in the light of placement
through correction of slippage from the center position, angle of the component.
Verify (CVS
：
Component Verification System)
The verification function is an option to be installed at the factory and it measures a capacitor
capacity, a resistance value and polarity of a component.
When a production program is created or during PWB production, this function measures only
the first component to check to see if a feeder is not mounted erroneously. It also checks the
first component after components run out or the first component every time the specified
number of PWBs are produced during production.
Vision data
Vision data is created for only a component whose “Centering method” is set to “Vision” on the
“Component data” screen. Enter mainly the information necessary for vision recognition such
as lead (ball) pitch, lead length, and the number of QFP, BGA into this vision data.
JUKI Corporation
2-11-1, Tsurumaki, Tama-shi, Tokyo 206-8551, Japan
Phone +81-42-357-2289 Facsimile +81-42-357-2285
EU DECLARATION OF CONFORMITY
We hereby declare that the following our product conforms with the essential health and
safety requirements of EU Directive. This declaration of conformity is issued under the
sole responsibility of the manufacturer.
Product
:
High-Speed Flexible Modular Mounter
Model
:
RS-1/RS-1XL /RS-1R
Serial No.
:
Manufacturer
:
JUKI Corporation
2-11-1, Tsurumaki, Tama-shi, Tokyo 206-8551, Japan
Authorized person to
compile the technical file
:
Hiroaki Yamazaki
JUKI Automation Systems GmbH,
Neuburger Strasse 41, DE-90451 Nuremberg, Germany
Directive
:
Machinery Directive 2006/42/EC
EMC Directive 2014/30/EU
RoHS Directive 2011/65/EU
The above product has been evaluated for conformity with above directive using the
following European standards. The technical construction file (TCF) for this product is
retained at the above manufacturer’s location.
Machinery Directive:
EN IS012100: 2010, EN 60204-1: 2006+A1:2009, EN ISO13849-1: 2015
EMC Directive:
EN 61000-6-4: 2007/A1:2011, EN 61000-6-2: 2005,
EN 61000-4-2: 2009, EN 61000-4-3: 2006/A1：2008/A2:2010,
EN 61000-4-4: 2012, EN 61000-4-5: 2006, EN 61000-4-6: 2014,
EN 61000-4-8: 2010, EN 61000-4-11: 2004
RoHS Directive
EN 50581:2012
Place and date of issue :
Tokyo, Japan, May 7, 2019
Name/Title : Toshimasa Miura
Director/Managing Officer/Quality Assurance Dept.
Being the responsible person appointed and employed by the manufacturer.
◆ Revision record
Rev. Date Revised locations Revision contents Remarks
00 Jan. 2017
First
edition
01 Mar. 2017 Full-fledged revision STEP2 Revision
02 Jul. 2017 Full-fledged revision STEP3 Revision
03 Oct. 2017 Chapter 3, 13 Add description Revision
04 Oct. 2017
1) 3.1.5 Air filter (LNC120-8 head)
2) EC DECLARATION OF
CONFORMITY
Addition Revision
05 Feb. 2018 Full-fledged revision JaNets Ver.1.06 Revision
06 Apr. 2018 Chapter 8 Change fixed jig Revision
07 Jul.2018 3-1-5, 3-4 Replacing the Filter Revision
08 Oct. 2018 Full-fledged revision
Addition of a machine for an extra-large board
and a 3-mm category
Revision
09 Jan. 2019 Full-fledged revision Addition of RS-1R Revised
10 Apr 2019 Chapter 4, Chapter 12 Added description of gripper nozzle Revised
11 May.2019 Chapter 3 Added head filter corresponding Rev. Revised
12 Sep.2019
1) Full-fledged revision
2) EC declaration of
conformity
1) -Addition of the description of
inspection/polishing of a nozzle
-Support of an RF72/88AS
-Addition of the description of
component pick-up position
correction
2) Responding to the change of EMC
directive
Revised
13 Nov.2019
1) For the safe operation of
machinery
2) Chapter 3
1) Modification of the position for pasting
a caution sticker and Modification of
the notes
2) Correction of the head revision
Revised
14 Jan. 2020
Chapter 8
Added function descriptions for
TraceMonitor and Splicing
Revised
15 Dec.2020
Chapter 2, 4, 7, 12
Added function Height check after placing Revised
