Chapter 7 Operation Option

7.1 Overview

When you select the [Options] command from the pull-down menu displayed after you start up the

“Operation option” utility, and then select the [Operation option] command, or when you select the

[Tool] command from the pull-own menu of the “Production” utility, and then select, the [Operation

option] command, the “Teaching” tab of the “Operation option” setting screen appears.

This utility allows you to set the operation conditions applied to data creation or production.

The items to be set as the operation options are shown in the table below.

No. Operation option group Option items

1 General

Explorer restricting function

Disable operation panel switches with the cover opened.

Data holding function at the end of system operation

2 Image (Teaching)

BOC alignment

Digital zoom

Use x4 zoom.

Auto teaching

Check the simultaneous pick enable range.

Do not perform auto teaching of pick height.

Mark auto teaching function

Upper limit value of mark size

Lower limit value of mark size

3 Image (Mark recognition)

Feeder bank recognition

Auto change of the threshold value of BOC mark

Lower limit value of the auto change of BOC recognition threshold value

Placement on the placement coordinates ignoring a solder recognition error.

Image (Mark recognizing

operation)

Prior recognition of BOC mark

Optimization of a BOC mark on each circuit

5 Production (Display)

Subtract the number of production PWBs.

Add the number of production PWBs.

Display the production screen by selecting Production Start (ONLINE).

Make no inquiry about storage at the end of production.

At non-stop production, “Non-stop production is not performed” is specified as the

default.

At non-stop production, “Production after re-clamp” is specified as the default.

At non-non-stop production, “Production after PWB inlet conveying” is specified as

the default.

Include “no components” in the number of pick errors.

Display a pick error at the start of production.

Subdivide errors at a temporary stop due to “no components.”

Worst feeder display method during production.

No output (Information of Coplanarity)

Only error electrode information (Information of Coplanarity)

All electrode information (Information of Coplanarity)

6 Production (Function)

Perform non-stop production at interruption of production.

Finish production when every circuit is provided with a bad mark.

Ignore transportation at dry run.

Control the residual number of components.

Consider the same component as an alternative feeder.

A vacuum check will not be run before production starts.

Operation at a cycle stop

Placing order of multiple circuits

Part 2 Detailed Description of Each Function Chapter 7 Operation Option

7-2

No. Operation option group Option items

7 Production (Action)

Simultaneous Nozzle Change

Check nozzle orientation.

Acquire nozzle height when attaching nozzle.

Auto-Correct pick position.

Do not place the component when a vacuum part existence check fails.

When components are picked up sequentially, they start moving before pick-up

check finishes completely.

Measure Height of PWB

Measure height of PWB immediately before placement

All Feed

VCS recognition retry

Check load of nozzle during production

Production operation during transportation of a board

The feed amount is adjusted by teaching.

The height of a component is inspected after it is placed on a board.

8 Production (Pause)

Temporary stop at occurrence of “no components”

Temporary stop at occurrence of an error

Temporary stop at a component drop

The <Replenish at no-components> button is added to the temporary stop screen.

Temporary stop at occurrence of a recognition error

Pause (When Copla check fails)

Place without checking (When Copla check fails)

Put into trash box (When Copla check fails)

9 Production (NonStop)

Non-stop operation

Alternate

Set masterBank to Rear

Non-stop operation (MTC)

Alternate (MTC)

Non-stop operation (MTS)

Alternate (MTS)

Non-stop operation (DTS)

10 Production (cueing)

Perform component cueing

Number of detected pieces

Threshold value of “existence/non-existence of components” (OCC cueing)

Threshold value of “existence/non-existence of components” (3216) (OCC cueing)

11 Production (Others)

Set 0 for the default of the scheduled number of production PWBs.

Disable the step No. input of production condition.

No feed at occurrence of a pick error when the retry is set to 0.

Pre-pick feed

Use ceramic PWBs.

Do not detect the nozzle return posture.

Tray draw speed: Low Speed 2

Hide message on production start.

High-density placement

(Print offset forward) Short side of applicable component dimensions

Tracking/Inspection

(Inspection enabled)

Detection of tombstone

Component dimension check

Component orientation check

Pick position offset check

Nozzle protrusion check

Component mis-release check function

Only Colinearity checked (Properties checked)

Colinearity and Coplanarity check (Properties checked)

Part 2 Detailed Description of Each Function Chapter 7 Operation Option

7-3

No. Operation option group Option items

Tracking/Inspection

(Inspecting operation)

Check component release after the placement Z goes up.

Component existence check near the laser height of 0

Measure the component height at as start after “no components”

Verify inspection at a start after “no components”

Auto verification of component executed.

Perform component verification after pick tracking.

Execute verify inspection after splicing.

Splicing detection mis-pick count (times)

Splicing detection area (mm)

Change angle (Change angle of coplanarity check)

Tracking/Inspection

(Tracking operation)

Pick tracking at a start after “no components”

Feeder unit for pick tracking

Cursor shape at component pick tracking

15 Optimization

(Optimization disabled) When the pick data “auto selection” is set

(Optimization disabled) Change the pick data except auto selection.

(Optimization disabled) Change the ATC nozzle setup.

16 Tray

Pick start position (Tray/DTS/MTS)

Pick direction (Tray/DTS/MTS)

Pick start position (MTC)

Pick direction (MTC)

Enable Auto Compo. presence check of MTC
