SEMI E36.1-0704 © SEMI 2004 8
RELATED INFORMATION 1
IDENTITY AND METADATA EXAMPLE
NOTICE: This related information is not an official part of SEMI E36.1 and was derived from the work of the
North American Information & Control committee. This related information was approved for publication by full
letter ballot on March 14, 2004.
R1-1 Identity and Metadata Example
R1-1.1 This section illustrates the use of the identity and metadata defined in the standard. The material shown
below was produced using a tool called the “RDF Validation Service” available on the web at
http://www.w3.org/RDF/Validator/. Given a candidate XML/RDF document, the tool will first validate the
document for compliance with the RDF specification. Next, the document is parsed and represented in three
alternative forms: the original XML version, a tabular version, and a graphical version.
R1-1.2 The graph shows that the sample RDF document contains five elements, as shown by the five ellipses on the
left side of the graphic. These items are the subjects of the RDF model. These are the items we are associating
metadata. Each subject has a URI embedded within; this URI points to the content that the subject refers to. This
binds metadata to a subject in a completely different context than that in which the subject’s content is developed.
R1-1.3 Emanating from the subjects are arrows. Each of these arrows defines a relationship between the subject and
another information item. The nature of the relationship is indicated as a label on the arc and corresponds to one of
the relationships defined in the E36 RDF model.
R1-1.4 These arrows terminate on graphics representing the object of the relationship. In cases where the
terminating graphic is a box, the object of the relationship is a literal value such as a number, date, or phrase. When
the terminating graphic is an oval, this is an indication that the object of the relationship is another resource. A URI
is embedded within the oval to identify which resource is being referred to.
R1-1.5 Original RDF/XML document
1: <?xml version='1.0' encoding='UTF-8'?>
2: <rdf:RDF
3: xmlns:rdf = 'http://www.w3.org/1999/02/22-rdf-syntax-ns#'
4: xmlns:rdfs = 'http://www.w3.org/2000/01/rdf-schema#'
5: xmlns:dc = 'http://purl.org/dc/elements/1.1/'
6: xmlns:e36base = 'http://www.semi.org/schemas/e36Base#'
7: >
8:
9: <e36base:Component rdf:about='D7C2E128-A1F2-4FAC-962F-00BA4E6150E5'>
10: <e36base:releaseDate>4/29/2003</e36base:releaseDate>
11: <dc:title>Cables</dc:title>
12: <dc:publisher>Some Publisher</dc:publisher>
13: <e36base:oemPartNumber>01-1010110</e36base:oemPartNumber>
14: <e36base:partName>Pump control</e36base:partName>
15: <e36base:oemName>Some OEM</e36base:oemName>
16: </e36base:Component>
17:
18: <e36base:Component rdf:about='C89722A8-2B03-4DDF-8ABD-68F01FCD2ADE'>
19: <e36base:releaseDate>4/29/2003</e36base:releaseDate>
20: <dc:title>Cables</dc:title>
21: <dc:publisher>Some Other Publisher</dc:publisher>
22: <e36base:oemPartNumber>02-1101001-01</e36base:oemPartNumber>
23: <e36base:partName>Power Cable</e36base:partName>
24: <e36base:oemName>Some Other OEM</e36base:oemName>
25: </e36base:Component>
26:
27: <e36base:Procedure rdf:about='CA46B949-B999-40B3-8554-2513DADEEBF7'>
28: <e36base:releaseDate>4/29/2003</e36base:releaseDate>
29: <dc:title>How To Use This Manual</dc:title>
30: <dc:publisher>A Publisher</dc:publisher>
31: <e36base:procedureType>OperationProcedure</e36base:procedureType>
32: </e36base:Procedure>
33:
34: <e36base:Recipe rdf:about='F9A6EB40-2DE4-4AF5-82C9-6C26E97BD197'>
35: <e36base:releaseDate>4/29/2003</e36base:releaseDate>
SEMI E36.1-0704 © SEMI 2004 9
36: <dc:title>Some Operation</dc:title>
37: <e36base:recipeType>ProcessRecipe</e36base:recipeType>
38: </e36base:Recipe>
39:
40: <e36base:SafetyItem rdf:about='0566910F-2C23-443F-B498-03B984735675'>
41: <e36base:releaseDate>4/29/2003</e36base:releaseDate>
42: <dc:title>Hazardous Material Detection</dc:title>
43: </e36base:SafetyItem>
44:
45: </rdf:RDF>
46:
Table R1-1 Triples of the Data Model
Number Subject Predicate Object
1
http://unknown.org/D7C2E12
8-A1F2-4FAC-962F-
00BA4E6150E5
http://www.w3.org/1999/02/22-
rdf-syntax-ns#type
http://www.semi.org/schemas/e
36Base#Component
2
http://unknown.org/D7C2E12
8-A1F2-4FAC-962F-
00BA4E6150E5
http://www.semi.org/schemas/e36
Base#releaseDate
" 4/29/2003"
3
http://unknown.org/D7C2E12
8-A1F2-4FAC-962F-
00BA4E6150E5
http://purl.org/dc/elements/1.1
/title
" Cables"
4
http://unknown.org/D7C2E12
8-A1F2-4FAC-962F-
00BA4E6150E5
http://purl.org/dc/elements/1.1
/publisher
" Some Publisher"
5
http://unknown.org/D7C2E12
8-A1F2-4FAC-962F-
00BA4E6150E5
http://www.semi.org/schemas/e36
Base#oemPartNumber
" 01-1010110"
6
http://unknown.org/D7C2E12
8-A1F2-4FAC-962F-
00BA4E6150E5
http://www.semi.org/schemas/e36
Base#partName
" Pump control"
7
http://unknown.org/D7C2E12
8-A1F2-4FAC-962F-
00BA4E6150E5
http://www.semi.org/schemas/e36
Base#oemName
" Some OEM"
8
http://unknown.org/C89722A
8-2B03-4DDF-8ABD-
68F01FCD2ADE
http://www.w3.org/1999/02/22-
rdf-syntax-ns#type
http://www.semi.org/schemas/e
36Base#Component
9
http://unknown.org/C89722A
8-2B03-4DDF-8ABD-
68F01FCD2ADE
http://www.semi.org/schemas/e36
Base#releaseDate
" 4/29/2003"
10
http://unknown.org/C89722A
8-2B03-4DDF-8ABD-
68F01FCD2ADE
http://purl.org/dc/elements/1.1
/title
" Cables"
11
http://unknown.org/C89722A
8-2B03-4DDF-8ABD-
68F01FCD2ADE
http://purl.org/dc/elements/1.1
/publisher
" Some Other Publisher"
12
http://unknown.org/C89722A
8-2B03-4DDF-8ABD-
68F01FCD2ADE
http://www.semi.org/schemas/e36
Base#oemPartNumber
" 02-1101001-01"
13
http://unknown.org/C89722A
8-2B03-4DDF-8ABD-
68F01FCD2ADE
http://www.semi.org/schemas/e36
Base#partName
" Power Cable"
14
http://unknown.org/C89722A
8-2B03-4DDF-8ABD-
68F01FCD2ADE
http://www.semi.org/schemas/e36
Base#oemName
" Some Other OEM"
15
http://unknown.org/CA46B94
9
-
B999
-
40B3
-
8554
-
http://www.w3.org/1999/02/22-
rdf-syntax-ns#type
http://www.semi.org/schemas/e
36Base#Procedure
SEMI E36.1-0704 © SEMI 2004 10
Number Subject Predicate Object
2513DADEEBF7
16
http://unknown.org/CA46B94
9-B999-40B3-8554-
2513DADEEBF7
http://www.semi.org/schemas/e36
Base#releaseDate
" 4/29/2003"
17
http://unknown.org/CA46B94
9-B999-40B3-8554-
2513DADEEBF7
http://purl.org/dc/elements/1.1
/title
" How To Use This Manual"
18
http://unknown.org/CA46B94
9-B999-40B3-8554-
2513DADEEBF7
http://purl.org/dc/elements/1.1
/publisher
" A Publisher"
19
http://unknown.org/CA46B94
9-B999-40B3-8554-
2513DADEEBF7
http://www.semi.org/schemas/e36
Base#procedureType
" OperationProcedure"
20
http://unknown.org/F9A6EB4
0-2DE4-4AF5-82C9-
6C26E97BD197
http://www.w3.org/1999/02/22-
rdf-syntax-ns#type
http://www.semi.org/schemas/e
36Base#Recipe
21
http://unknown.org/F9A6EB4
0-2DE4-4AF5-82C9-
6C26E97BD197
http://www.semi.org/schemas/e36
Base#releaseDate
" 4/29/2003"
22
http://unknown.org/F9A6EB4
0-2DE4-4AF5-82C9-
6C26E97BD197
http://purl.org/dc/elements/1.1
/title
" Some Operation"
23
http://unknown.org/F9A6EB4
0-2DE4-4AF5-82C9-
6C26E97BD197
http://www.semi.org/schemas/e36
Base#recipeType
" ProcessRecipe"
24
http://unknown.org/0566910
F-2C23-443F-B498-
03B984735675
http://www.w3.org/1999/02/22-
rdf-syntax-ns#type
http://www.semi.org/schemas/e
36Base#SafetyItem
25
http://unknown.org/0566910
F-2C23-443F-B498-
03B984735675
http://www.semi.org/schemas/e36
Base#releaseDate
" 4/29/2003"
26
http://unknown.org/0566910
F-2C23-443F-B498-
03B984735675
http://purl.org/dc/elements/1.1
/title
" Hazardous Material Detection"
