SEMI M6-1000 © SEMI 1981, 20005

8.2 In the interest of controlling in spection costs, the

supplier and the purchaser may agree that the material

shall be certified as ‘capable of meeting’ certain

requirements. In this context, ‘capable of meeting’ shall

signify that the supplier is not required to perform the

appropriate tests in Section 7. However, if the purchaser

performs the test and the material fails to meet the

requirement, the material may be subject to rejection.

9 Packing and Package Lab eling

9.1 Special packing requirements shall be subject to

agreement between the supplier and the purchaser.

Otherwise all wafers shall be handled, inspected, and

packed in such a manner as to avoid chipping,

scratches, and contamination, and in accordance with

the best industry practices to provide ample protection

against damage during shipment.

9.2 The wafers supplied under these specifications

shall be identified by appropriately labeling the outside

of each box or other container and each subdivision

thereof in which it may reasonably be expected that the

wafers will be stored prior to further processing.

Identification shall include as a minimum the nominal

diameter, conductivity type, dopant, orientation,

resistivity range, and lot number. The lot number, either

(1) assigned by the original manufacturer of the wafers,

or (2) assigned subsequent to wafer manufacture but

providing reference to the original lot number, shall

provide easy access to information concerning the

fabrication history of the particular wafers in that lot.

Such information shall be retained on file at the

manufacturer’s facility for at least one year after that

particular lot has been accepted by the purchaser.

SEMI M6-1000 © SEMI 1981, 2000 6

Figure 1

Rectangular Mainly Square Photovoltaic Solar Cell Silicon Wafer Dimensions

Table 2 Rectangular Mainly Square Photovoltaic Solar Cell Silicon Wafer Dimensions (letters as in Figure 1)

Nominal Size (mm) Dimensions (mm)

ABCD

Max. Min. Max. Min. Max. Min. Max. Min.

100 101 99 101 99 142.8 140.0 2.0 0.5

125 126 124 126 124 187.2 175.4 2.0 0.5

150 151 149 151 149 213.5 210.7 2.0 0.5

200 201 199 201 199 284.3 281.4 2.0 0.5

CDD

Figure 2

Pseudo-Square Monocrystalline Photovoltaic Solar Cell Silicon Wafer Dimensions

Table 3 Pseudo-Square Monocrystalline Photovoltaic Solar Cell Silicon Wafer Dimensions (letters as in

Figure 2)

Nominal size (mm) Dimensions (mm)

ABCD

Min. Max. Min. Max. Min. Max. Min. Max.

100 99 101 124 126 71.9 77.9 10.6 14.6

125 124 126 149 151 79.5 86.2 23.2 28.9

150 149 151 174 176 86.4 93.7 27.6 32.3
