SEMI T12.1-0704 © SEMI 2004 1
SEMI T12.1-0704
SPECIFICATION FOR SECS PROTOCOL FOR TRACKING JIGS AND
IMPLEMENTS
This specification was technically approved by the Global Traceability Committee and is the direct
responsibility of the Japanese Traceability Committee. Current edition approved by the Japanese Regional
Standards Committee on April 30, 2004. Initially available at www.semi.org June 2004; to be published July
2004.
1 Purpose
1.1 The purpose of this document is to map Services and data in Specification of Tracking Jig and Implements into
SECS protocol.
2 Scope
2.1 This document is applied to SECS implementation of Jigs and Implements traceability with some
interoperability with semiconductor Manufacturing Execution System (MES).
NOTICE: This standard does not purport to address safety issues, if any, associated with its use. It is the
responsibility of the users of this standard to establish appropriate safety and health practices and determine the
applicability of regulatory or other limitations prior to use.
3 Referenced Standards
3.1 SEMI Standards
SEMI E5 — SEMI Equipment Communication Standard 2 Message Content (SECS-II)
SEMI E39 — Object Service Standard: Concepts, Behavior and Services
SEMI T12 — Specification for Tracing Jigs and Implements
NOTICE: Unless otherwise indicated, all documents cited shall be the latest published versions.
4 Requirements
4.1 Service Mapping — This specification maps service instructions defined in “Specification for Jigs and
Implements” into SECS stream/functions as follows. Supporting Class names specified in the following table are
used as OBJSPEC or a part of OBJSPEC to request services.
Table 1 Service Message Instruction Mapping
Service Message Name Supporting Class Stream, Function SECS-II Message Name
addEvent HistoryRecord S14, F19/F20 Generic Service Request / Response
adopt HistoryDB S14, F19/F20 Generic Service Request / Response
changeAction Expiry S14, F19/F20 Generic Service Request / Response
changeDescription Expiry S14, F19/F20 Generic Service Request / Response
changeExpiration Expiry S14, F19/F20 Generic Service Request / Response
changeName Attachment, PublicLocation,
Secondment
S14, F19/F20 Generic Service Request / Response
changeNamespace Inventory S14, F19/F20 Generic Service Request / Response
destrcut Exception, Expiry, HistoryBuffer,
HistoryRecord, Secondment
S14, F19/F20 Generic Service Request / Response
disown HistoryDB S14, F19/F20 Generic Service Request / Response
fluctuate HistoryRecord S14, F19/F20 Generic Service Request / Response
install Inventory S14, F19/F20 Generic Service Request / Response
listEvent HistoryRecord S14, F19/F20 Generic Service Request / Response
SEMI T12.1-0704 © SEMI 2004 2
Service Message Name Supporting Class Stream, Function SECS-II Message Name
listRecords HistoryDB S14, F19/F20 Generic Service Request / Response
listUp Inventory S14, F19/F20 Generic Service Request / Response
receiveInvoice JitMachine S14, F19/F20 Generic Service Request / Response
reset HistoryDB S14, F19/F20 Generic Service Request / Response
setReleaseCondition HistoryBuffer S14, F19/F20 Generic Service Request / Response
showAction Expiry S14, F19/F20 Generic Service Request / Response
showAttachment HistoryBuffer S14, F19/F20 Generic Service Request / Response
showAttachments Invoice, JitMachine,
PublicLocation
S14, F19/F20 Generic Service Request / Response
showAvailableSpace PublicLocation S14, F19/F20 Generic Service Request / Response
showCapacity PublicLocation S14, F19/F20 Generic Service Request / Response
showCategory Exception S14, F19/F20 Generic Service Request / Response
showCode Exception S14, F19/F20 Generic Service Request / Response
showData Inventory S14, F19/F20 Generic Service Request / Response
showDescription Exception, Expiry S14, F19/F20 Generic Service Request / Response
showEvent HistoryRecord S14, F19/F20 Generic Service Request / Response
showExeptions JitMachine S14, F19/F20 Generic Service Request / Response
showExpiration Expiry S14, F19/F20 Generic Service Request / Response
showHistory Attachment, HistoryBuffer,
HistoryDB, HistoryRecord, Invoice
S14, F19/F20 Generic Service Request / Response
showId Attachment, Exception, Expiry,
Invoice, JitMachine,
PublicLocation, Secondment
S14, F19/F20 Generic Service Request / Response
showLoadports Invoice S14, F19/F20 Generic Service Request / Response
showLocationType PublicLocation S14, F19/F20 Generic Service Request / Response
showName Attachment, JitMachine,
PublicLocation, Secondment
S14, F19/F20 Generic Service Request / Response
showNamespace Inventory S14, F19/F20 Generic Service Request / Response
showOccupancy PublicLocation S14, F19/F20 Generic Service Request / Response
showPossibleType PublicLocation S14, F19/F20 Generic Service Request / Response
showReleaseCondition HistoryBuffer S14, F19/F20 Generic Service Request / Response
showState Exception, Expiry, HistoryBuffer,
PublicLocation, Secondment
S14, F19/F20 Generic Service Request / Response
showSubject Exception, Expiry S14, F19/F20 Generic Service Request / Response
showType Attachment, JitMachine,
Secondment
S14, F19/F20 Generic Service Request / Response
showTypes Invoice S14, F19/F20 Generic Service Request / Response
uninstall Inventory S14, F19/F20 Generic Service Request / Response
update HistoryDB, Inventory S14, F19/F20 Generic Service Request / Response
updateHistory Attachment, Exception,
HistoryBuffer
S14, F19/F20 Generic Service Request / Response
updateState PublicLocation S14, F19/F20 Generic Service Request / Response
4.2 Service Parameter Mapping — The Following Table shows the mapping between service parameters defined by
“Specification for Tracking Jigs and Implements” standard and Data Items defined by SEMI E5. The data item
SVCNAME used with S14F19 is the text string defined in the above table. The data item SPNAME used with
S14F19/F20 is also text string defined in following table. It is recommended but not limited to be case sensitive for
both data items for future extension.
SEMI T12.1-0704 © SEMI 2004 3
Table 2 Service Message Parameter Mapping
Parameter Name SECS-II Data Item Reference SECS-II Format Remarks
Action L, 2
1. <SPNAME>
2. <SPVAL>
SPNAME = Action
SPVAL = (20)
AttachmentId L, 2
1. <SPNAME>
2. <SPVAL>
SPNAME = AttachmentId
SPVAL = (20)
AttachmentInfo L, 2
1. <SPNAME>
2. <SPVAL>
SPNAME = AttachmentInfo
SPVAL = (20)
AttachmentName L, 2
1. <SPNAME>
2. <SPVAL>
SPNAME = AttachmentName
SPVAL = (20)
AttachmentType L, 2
1. <SPNAME>
2. <SPVAL>
SPNAME = AttachmentType
SPVAL = (20)
Space separated enumeration
if more than one enumerated
items.
Capacity L, 2
1. <SPNAME>
2. <SPVAL>
SPNAME = Capacity
SPVAL = (51, 52, 54)
Category L, 2
1. <SPNAME>
2. <SPVAL>
SPNAME = Category
SPVAL = (20)
Code L, 2
1. <SPNAME>
2. <SPVAL>
SPNAME = Code
SPVAL = (20)
Condition L, 2
1. <SPNAME>
2. <SPVAL>
SPNAME = Condition
SPVAL = (20)
DataName L, 2
1. <SPNAME>
2. <SPVAL>
SPNAME = DataName
SPVAL = (20)
DataValue L, 2
1. <SPNAME>
2. <SPVAL>
SPNAME = DataValue
SPVAL = (00, 1x, 2x, 3x, 4x, 5x)
“x” is an appropriate octal
defined in SEMI E5.
Description L, 2
1. <SPNAME>
2. <SPVAL>
SPNAME = Description
SPVAL = (20)
EventCaption L, 2
1. <SPNAME>
2. <SPVAL>
SPNAME = EventCaption
SPVAL = (20)
ExceptionId L, 2
1. <SPNAME>
2. <SPVAL>
SPNAME = ExceptionId
SPVAL = (20)
numeric or alpha-numeric
Expiration L, 2
1. <SPNAME>
2. <SPVAL>
SPNAME = Expiration
SPVAL = (20)
ExpiryId L, 2
1. <SPNAME>
2. <SPVAL>
SPNAME = ExpiryId
SPVAL = (20)
