SEMI S8-0705 © SEMI 1995, 2005 27
Body Part
Awkward Posture
#1
(angle in degrees from neutral)
Comments Image
Head / Neck
10. Neck flexion > 20 Neck flexion is bending the neck
forward (e.g., looking downward).
11. Neck extension > 0 Neck extension is bending the neck
back (e.g., looking up).
10 11
12. Neck lateral
flexion
> 20 Neck bent with the ear toward the
shoulder.
13. Head rotation > 45 Neck rotation is turning the neck (e.g.,
looking to the side).
12 13
Back (Standing)
14. Back bend,
forward flexion
> 20 Definition of “Awkward Posture”
applies if posture is static.
15. Back twist > 30 Measured from mid-sagittal plane of
body.
Note: mid-sagittal plane is defined as a
plane line drawn down the mid-line of
the body, perpendicular to the back.
14 15
16. Lateral bend > 20 Bend to the side of the body.
16
SEMI S8-0705 © SEMI 1995, 2005 28
Body Part
Awkward Posture
#1
(angle in degrees from neutral)
Comments Image
Seated Postures
17. Elbow flexion < 90, OR > 120 A 90 elbow angle is defined as the
theoretical “neutral” position.
18. Back trunk-thigh
angle
< 90 Increasing the trunk-thigh angle
reduces pressure on the lower back.
17 18
19. Knee angle < 90 Increasing the angle at the knees
reduces stress at the knees.
19
#1
Joint angles adapted from Humanscale 7/8/9, The MIT Press, Massachusetts Institute of Technology, Cambridge, MA, 1981.
SEMI S8-0705 © SEMI 1995, 2005 29
R1-3 Maximum Recommended Grip Forces
R1-3.1 The grip forces in Table R1-4 are based upon percentages of maximum one-time grip forces. These values
differ from maximum hand grip force values in Appendix 1: Supplier Ergonomic Success Criteria ¶6.7.1.1 through
¶6.9.2, which are maximum values for lift or pull forces based upon comfort and contact pressure against the hand.
Table R1-4 Maximum Recommended Grip Forces
Maximum Force
Grip Type Image Glove Use
Infrequent
Tasks
Repetition is
less than once
every 5 minutes
Occasional
Tasks
Tasks with a
repetition rate
between that of an
infrequent and a
f
requent tas
k
Static or
Frequent Tasks
Duration greater
than 4 seconds or
repeated more than
once every 30
seconds
Grip
without
gloves
137 N
(30.9 lbf.)
82 N
(18.5 lbf.)
41 N
(9.4 lbf.)
Grip with
cleanroom
gloves
116 N
(26.3 lbf.)
70 N
(15.7 lbf.)
35 N
(8.0 lbf.)
Power Grip:
The fingers of the hand wrap
around the object, and the
thumb overlaps the index
finger (e.g., gripping a
hammer).
Grip with
chemical
gloves
111 N
(25.0 lbf.)
66 N
(15.0 lbf.)
33 N
(7.6 lbf.)
Grip
without
gloves
35 N
(7.9 lbf.)
21.8 N
(4.9 lbf.)
10.7 N
(2.4 lbf.)
Grip with
cleanroom
gloves
30 N
(6.7 lbf.)
19 N
(4.2 lbf.)
9 N
(2.0 lbf.)
Lateral Pinch:
Object is held between the
thumb and the side of the index
finger (often referred to as key
grip).
Grip with
chemical
gloves
28 N
(6.4 lbf.)
18 N
(4.0 lbf.)
9 N
(1.9 lbf.)
Grip
without
gloves
24.5 N
(5.5 lbf.)
14.7 N
(3.3 lbf.)
7.6 N
(1.7 lbf.)
Grip with
cleanroom
gloves
21 N
(4.7 lbf.)
13 N
(2.8 lbf.)
7 N
(1.4 lbf.)
Tip Pinch:
Object held between the tips of
the thumb and index finger.
Grip with
chemical
gloves
20 N
(4.5 lbf.)
12 N
(2.7 lbf.)
6 N
(1.4 lbf.)
Grip
without
gloves
36 N
(8.2 lbf.)
21.6 N
(4.85 lbf.)
11.1 N
(2.5 lbf.)
Grip with
cleanroom
gloves
31 N
(7.0 lbf.)
18 N
(4.1 lbf.)
9 N
(2.1 lbf.)
Palmar Pinch:
Fingers pressed against the
palm of the hand, with the
object held between the fingers
and the palm. Thumb is not
used (e.g., picking up a sheet of
plywood).
Grip with
chemical
gloves
29 N
(6.6 lbf.)
18 N
(3.9 lbf.)
9 N
(2.0 lbf.)
