SEMI E54.7-0999 © SEMI 19997
Table 5 Assembly Object Instance Attributes and
Services
ASSEMBLY Object (Asm)
Class ID == 03, Instance ID = 01 through i
Attributes
ID Attribute Name CDM Tag
01 Data AsmA1
Services
ID Service Name CDM Tag
07 Get Attribute AsmS4
09 Set Attribute AsmS5
7.5 Local Link Object (Lnk) –– The Local Link (Lnk)
object instances may be used to ‘link” an attribute of
one object instance to an attribute of another object
instance. The presentation of object instance attributes
and services are as indicated in Table 6.
Table 6 Local Link Object Instance Attributes and
Services
Local Link Object (Asm)
Class ID = 04, Instance ID = 01 through j
Attributes
ID Attribute Name CDM Tag
01 Source Object Class LnkA1
02 Source Object Instance LnkA2
03 Source Object Attribute LnkA3
04 Destination Object Class LnkA4
05 Destination Object Instance LnkA5
06 Destination Object Attribute LnkA6
07 Commit LnkA7
Services
ID Service Name CDM Tag
-- No services defined --
7.6 Sensor-AI Object (Sai) –– The presentation of the
Sensor Analog Input (Sensor-AI) object instance
attributes and services are as indicated in Table 7.
Table 7 Sensor-AI Object Instance Attributes and
Services
Sensor-AI
Class ID = 33, Instance ID = 01 through k
Attributes
ID Attribute Name CDM Tag
01 Name SaiA1
02 Status SaiA2
03 Alarm Enable SaiA3
04 Warning Enable SaiA5
16 Value Sai16
17 ReportInhibitTimer Sai17
18 EnableReportRate Sai18
19 ReportRate Sai19
64 Offset Sai64
65 Gain Sai65
66 DataType Sai66
67 DataUnits Sai67
68 SafeState Sai68
69 EnableReportDelta Sai69
70 ReportDelta Sai70
71 EnableReportROC Sai71
72 AlarmTripPointHigh Sai72
73 AlarmTrippointLow Sai73
74 AlarmHystersis Sai74
75 WarningTripPointHigh Sai75
76 WarningTripPointLow Sai76
77 WarningHystersis Sai77
Services
ID Service Name SDM Tag
01 Reset SaiS1
03 Abort SaiS2
05 Recover SaiS3
25 Operate SaiS4
07 GetAttribute SaiS5
09 SetAttribute SaiS6
27 RestoreDefault SaiS7
7.7 Sensor-EI Object (Sei) –– The presentation of the
Sensor Enumerated Input (Sensor-EI) object instance
attributes and services are as indicated in Table 8.
SEMI E54.7-0999 © SEMI 1999 8
Table 8 Sensor-EI Object Instance Attributes and
Services
Sensor-EI
Class ID = 34, Instance = 01 through l
Attributes
ID Attribute Name CDM Tag
01 Name SeiA1
02 Status SeiA2
03 Alarm Enable SeiA3
04 Warning Enable SeiA5
16 Value Sei16
17 ReportInhibitTimer Sei17
18 EnableReportRate Sei18
19 ReportRate Sei19
64 DebounceControl Sei64
65 AlarmStatus Sei65
66 WarningStatus Sei66
Services
ID Service Name SDM Tag
01 Reset SeiS1
03 Abort SeiS2
05 Recover SeiS3
25 Operate SeiS4
07 GetAttribute SeiS5
09 SetAttribute SeiS6
27 RestoreDefault SeiS7
7.8 Sensor-BI Object (Sbi) –– The presentation of the
Sensor Binary Input (Sensor-BI) object instance
attributes and services are as indicated in Table 9.
Table 9 Sensor-BI Object Instance Attributes and
Services
Sensor-BI
Class ID = 35, Instance ID = 01 through m
Attributes
ID Attribute Name CDM Tag
01 Name SbiA1
02 Status SbiA2
03 Alarm Enable SbiA3
04 Warning Enable SbiA5
16 Value Sbi16
17 ReportInhibitTimer Sbi17
18 EnableReportRate Sbi18
19 ReportRate Sbi19
64 DebounceControl Sbi64
65 AlarmStatus Sbi65
66 WarningStatus Sbi66
Services
ID Service Name SDM Tag
01 Reset SbiS1
03 Abort SbiS2
05 Recover SbiS3
25 Operate SbiS4
07 GetAttribute SbiS5
09 SetAttribute SbiS6
27 RestoreDefault SbiS7
7.9 Actuator-AO Object (Aao) –– The presentation of
the Actuator Analog Output (Actuator-AO) object
instance attributes and services are as indicated in Table
10.
Table 10 Actuator-AO Object Instance Attributes
and Services
Actuator-AO
Class ID = 36, Instance = 01 through n
Attributes
ID Attribute Name CDM Tag
01 Name AaoA1
02 Status AaoA2
03 Alarm Enable AaoA3
04 Warning Enable AaoA5
16 Setting Aao16
17 SafeState Aao17
18 WatchRate Aao18
19 Watchdog Aao19
64 Offset Aao64
65 Gain Aao65
66 DataType Aao66
67 DataUnits Aao67
Services
ID Service Name SDM Tag
01 Reset AaoS1
03 Abort AaoS2
05 Recover AaoS3
25 Operate AaoS4
07 GetAttribute AaoS5
09 SetAttribute AaoS6
27 RestoreDefault AaoS7
SEMI E54.7-0999 © SEMI 19999
7.10 Actuator-EO Object (Aeo) –– The presentation of
the Actuator Enumerated Output (Actuator-EO) object
instance attributes and services are as indicated in Table
11.
Table 11 Actuator-EO Object Instance Attributes
and Services
Actuator-EO
Class ID = 37, Instance ID = 01 through o
Attributes
ID Attribute Name CDM Tag
01 Name AeoA1
02 Status AeoA2
03 Alarm Enable AeoA3
04 Warning Enable AeoA5
16 Setting Aeo16
17 SafeState Aeo17
18 WatchRate Aeo18
19 Watchdog Aeo19
Services
ID Service Name SDM Tag
01 Reset AeoS1
03 Abort AeoS2
05 Recover AeoS3
25 Operate AeoS4
07 GetAttribute AeoS5
09 SetAttribute AeoS6
27 RestoreDefault AeoS7
7.11 Actuator-BO Object (Abo) –– The presentation of
the Actuator Binary Output (Actuator-BO) object
instance attributes and services are as indicated in Table
12.
Table 12 Actuator-BO Object Instance Attributes
and Services
Actuator-BO
Class ID = 38, Instance ID = 01 through p
Attributes
ID Attribute Name CDM Tag
01 Name AboA1
02 Status AboA2
03 Alarm Enable AboA3
04 Warning Enable AboA5
16 Setting Abo16
17 SafeState Abo17
18 WatchRate Abo18
19 Watchdog Abo19
Services
ID Service Name SDM Tag
01 Reset AboS1
03 Abort AboS2
05 Recover AboS3
25 Operate AboS4
07 GetAttribute AboS5
09 SetAttribute AboS6
27 RestoreDefault AboS7
7.12 Controller Object (CA) –– The presentation of
the Controller (CA) object instance attributes and
services are as indicated in Table 13.
Table 13 Controller-CA Object Instance Attributes
and Services
Controller
Class ID = 39, Instance ID = 01 through q
Attributes
ID Attribute Name CDM Tag
01 Name CAA1
02 Status CAA2
03 Alarm Enable CAA3
04 Warning Enable CAA4
16 Setpoint CAA16
17 ProcessVariable CAA17
18 ControlVariable CAA18
19 DataType CAA19
64 DataUnits CAA20
65 AlarmSettleTime CAA21
66 AlarmErrorBand CAA22
67 WarningSettleTime CAA23
68 WarningErrorBand CAA24
Services
ID Service Name SDM Tag
01 Reset CAS1
03 Abort CAS2
05 Recover CAS3
25 Operate CAS4
07 GetAttribute CAS5
09 SetAttribute CAS6
27 RestoreDefault CAS7
