SEMI S1-0701
E
© SEMI 1986, 2001 13
# Referent Source Symbol Description
8
Drop,
Fall Hazard
IEC 61310
Person falling
9
Lifting Hazard,
Heavy Object
Person bent over weight, strain flare above
back
10
Tipover
Person with object tipping over and arrow
11
Entanglement
Hazard
(hand in gears)
ANSI Z535.3
Hand in gears
Note: other body parts or orientations may
be substituted as necessary
12
Pinch point
(hand in rollers)
ANSI Z535.4
Hand in rollers
Note: other body parts or orientations may
be substituted as necessary
13
Cut/Sever
(hand and sharp
object)
ANSI Z535.3
Hand and sharp object
Note: other body parts or orientations may
be substituted as necessary
14
Crush Hazard
Hand between two surfaces, arrow
Note: other body parts or orientations may
be substituted as necessary
15
Heat,
Hot Surface
ISO 3864, ISO 7000
Heat waves
16
Cold
Snow flake
17
Strong Magnetic
Field
Horseshoe magnet
SEMI S1-0701
E
© SEMI 1986, 2001 14
# Referent Source Symbol Description
18
Radioactive
Material,
Radiation Hazard
IEC 61310
Abstract three blades
19
Laser Beam IEC 60825-1
Radiating sunburst, line
20
Biological Risk,
Biohazard
IEC 61310
Abstraction
21
Non-Ionizing
Radiation,
Radio Frequency
IEC 61310
Abstract radiation transmitter
22
UV Light Hazard
The letters “UV” inside a sunburst
23
Inhalation Hazard
(e.g., toxic gas,
asphyxiation
hazard)
Human figure breathing in particles
24
General Warning
(should be
supplemented with
words)
ISO 3864
Exclamation point
(See Figure 6 for an example of a safety
label using the General Warning symbol)
Table A1-2 Mandatory Action Symbols
# Referent Source Symbol Description
1
Wear Eye
Protection
IEC 61310
Head with eyeglasses
2
Wear Ear
Protection
IEC 61310
Head with ear protection
SEMI S1-0701
E
© SEMI 1986, 2001 15
# Referent Source Symbol Description
3
Wear Head
Protection
IEC 61310
Head with hard hat
4
Wear Respiratory
Protection
IEC 61310
Head with respirator
5
Wear Safety Boots IEC 61310
Shoes
(one with metal plate shown)
6
Wear Safety Gloves IEC 61310
Two gloves
7
Lift with
Mechanical
Assistance
Mechanical jack supporting object
8
Lift with Two
Persons
Two persons grasping object
9
Read Manual
Person reading open book
10
Lock Out in De-
Energized State
ON and OFF symbols next to locked clasp
