SEMI E134.1-0305 © SEMI 2005 55
Figure 38
CollectedDataType
Table 116 Translation Table for CollectedDataType
Attribute or Role Name UML Type
XML Element or Attribute
(or Reference)
XML Name/Type
parameterValues Ordered list of zero or more
elements of type
ParameterValue
Element PV: dcm:ParameterValueType
collectionTime Text Attribute collectionTime: xsd:dateTime
SEMI E134.1-0305 © SEMI 2005 56
7.3.6 PerformanceWarning
7.3.6.1 WSDL Operation Binding
7.3.6.1.1 See the operation binding for “PerformanceWarning” in E134-Client-Binding.wsdl. Key information is
shown for convenience in the following table.
Table 117 PerformanceWarning Operation Binding
SOAPAction
urn:semi-org:ws.E134-1.V0305.DCPConsumer-binding:PerformanceWarning
Input Headers (WSDL Message, Required) E132HashHeaderMessage, required
7.3.6.2 WSDL Operation
7.3.6.2.1 See the portType operation definition for “PerformanceWarning” in E134-Client-PortType.wsdl. Key
information is shown for convenience in the following table.
Table 118 PerformanceWarning PortType Operation
Input Message Name PerformanceWarningNotification
7.3.6.3 WSDL Message(s)
7.3.6.3.1 See the message definitions for “E132HashHeaderMessage” and “PerformanceWarningNotification” in
E134-Client-PortType.wsdl. Key information is shown for convenience in the following table.
Table 119 DCPConsumer Binding
Message Name
Schema
Element Name
E132HashHeaderMessage auth:E132HashHeader
PerformanceWarningNotification dcm:PerformanceWarningNotificationType
7.3.6.4 XML Schema Types
Figure 39
PerformanceWarningNotification
7.3.6.4.1 PerformanceWarningNotification — This global element acts as a top-level container entity representing
the SOAP body of a PerformanceWarning notification. As defined in SEMI E134, this operation has one output
argument: the warning. This argument is modeled as an attributes named “Warning” of complexType
“PerformanceStatusType”.
SEMI E134.1-0305 © SEMI 2005 57
Table 120 Translation Table for Input Arguments for the PerformanceWarning Operation
Argument Name Format XML Element or Attribute XML Name/Type
warning Structured data, of type
PerformanceStatus
Element Warning : dcm: PerformanceStatusType as
described in ¶7.2.20.4.3
7.3.7 PerformanceRestored
7.3.7.1 WSDL Operation Binding
7.3.7.1.1 See the operation binding for “PerformanceRestored” in E134-Client-Binding.wsdl. Key information is
shown for convenience in the following table.
Table 121 PerformanceRestored Operation Binding
SOAPAction
urn:semi-org:ws.E134-1.V0305.DCPConsumer-binding:PerformanceRestored
Input Headers (WSDL Message, Required) E132HashHeaderMessage, required
7.3.7.2 WSDL Operation
7.3.7.2.1 See the portType operation definition for “PerformanceRestored” in E134-Client-PortType.wsdl. Key
information is shown for convenience in the following table.
Table 122 PerformanceRestored PortType Operation
Input Message Name PerformanceRestoredNotification
7.3.7.3 WSDL Message(s)
7.3.7.3.1 See the message definitions for “E132HashHeaderMessage” and “PerformanceRestoredNotification” in
E134-Client-PortType.wsdl. Key information is shown for convenience in the following table.
Table 123 DCPConsumer Binding
Message Name
Schema
Element Name
E132HashHeaderMessage auth:E132HashHeader
PerformanceRestoredNotification dcm:PerformanceRestoredNotificationType
7.3.7.4 XML Schema Types
Figure 40
PerformanceRestoredNotification
