SEMI E86-0200 © SEMI 1999 , 2000 6 /* Person lifecycle event definition. */ const string PersonLifecycleSubject = "/PersonManagement/PersonManager/PersonLifecycle" ; typedef struct PersonLifecycleFilters_Struct…

SEMI E86-0200 © SEMI 1999, 20005

typedef IntervalT TimeWindow ;

typedef struct Shift_Structure {

string name ;

// ...

} Shift ;

typedef struct PersonResponsibilitystruct {

string responsibilityCategory ;

any responsibility ;

} PersonResponsibility;

typedef sequence<ProcessCapability> ProcessCapabilitySequence ;

typedef stringSequence CategorySequence ;

typedef sequence<HistoryEvent> HistoryEventSequence ;

typedef sequence<Job> JobSequence ;

typedef sequence<Machine> MachineSequence ;

typedef sequence<Person> PersonSequence ;

typedef sequence<QualificationData> QualificationDataSequence ;

typedef sequence<Resource> ResourceSequence ;

typedef sequence<SkillRequirement> RequirementSequence ;

typedef sequence<PersonResponsibility> ResponsibilitySequence ;

typedef sequence<Skill> SkillSequence ;

typedef string PropertyName;

struct Property

{

PropertyName property_name;

any property_value;

};

typedef sequence<Property> Properties;

6.2.5 Global Exception Declarations

6.2.5.1 An exception is an infrastructure mechanism used to notify a calling client of an operation that an unusual

condition occurred in carrying out the operation. This section identifies the global exception declarations required by

the Factory Labor component specification.

exception FrameworkErrorSignal {

unsigned long errorCode ;

any errorInformation ;

};

exception InvalidStateTransitionSignal {

};

exception SetValueOutOfRangeSignal {

};

6.2.6 Events

6.2.6.1 An event is an asynchronous message denoting the occurrence of some incident of importance. For

example, state change or new object created. This section identifies the events defined by the Factory Labor

component specification. Note that “//” or “/* ....*/” infers a comment.

SEMI E86-0200 © SEMI 1999, 2000 6

/* Person lifecycle event definition. */

const string PersonLifecycleSubject =

"/PersonManagement/PersonManager/PersonLifecycle" ;

typedef struct PersonLifecycleFilters_Structure {

Property name; // “Name”, aPerson’s name

Property lifecycleEvent; // “LifecycleEvent”, LifecycleState

} PersonLifecycleFilters;

typedef struct PersonLifecycleEvent_Structure {

string eventSubject;

TimeStamp eventTimeStamp;

PersonLifecycleFilters eventFilterData;

Properties eventNews;

Person aPerson;

// Except when “Delete” where value will be nil

} PersonLifecycleEvent;

/* Person capacity changed event definition. */

const string PersonCapacityChangedSubject =

"/PersonManagement/Person/CapabilityChanged" ;

typedef struct PersonCapacityChangedFilters_Structure {

Property name; // “Name”, aPerson’s name

} PersonCapacityChangedFilters;

typedef struct PersonCapacityChangedEvent_Structure {

string eventSubject;

TimeStamp eventTimeStamp;

PersonCapacityChangedFilters eventFilterData;

Properties eventNews;

Person aPerson;

} PersonCapacityChangedEvent;

/* Person state changed event definition. */

const string PersonStateChangedSubject = "/PersonManagement/Person/StateChanged";

enum PersonState {PersonDefined, PersonOffShift, PersonOnShift,

PersonAvailableForWork, PersonNotAvailableForWork, PersonUnassignedToMachines,

PersonAssignedToJobs, PersonAssignedToMachines, PersonAvailableForMoreAssignments,

PersonAssignmentAtCapacityExceeded, PersonIdleWithJob, PersonBusyWithJob };

typedef struct PersonStateChangedFilters_Structure {

Property name; // “Name”, aPerson’s name

Property formerState; // “FormerState”, PersonState

Property newState; // “NewState”, PersonState

} PersonStateChangedFilters;

typedef struct PersonStateChangedEvent_Structure {

string eventSubject;

TimeStamp eventTimeStamp;

PersonStateChangedFilters eventFilterData;

Properties eventNews;

Person aPerson;

} PersonStateChangedEvent;

/* Person shift worked changed event definition. */

const string PersonShiftChangedSubject = "/PersonManagement/Person/ShiftChanged";

typedef struct PersonShiftChangedFilters_Structure {

Property name; // “Name”, aPerson’s name

Property fromShift; // “FromShift”, former shift

SEMI E86-0200 © SEMI 1999, 20007

Property toShift; // “ToShift”, new shift

} PersonShiftChangedFilters;

typedef struct PersonShiftChangedEvent_Structure {

string eventSubject;

TimeStamp eventTimeStamp;

PersonShiftChangedFilters eventFilterData;

Properties eventNews;

Person aPerson;

} PersonShiftChangedEvent;

6.3 Person Management Component

6.3.1 This component defines factory personnel (Person interface) to a CIM system. Persons are viewed as resour-

ces in the manufacturing environment, are assigned to a factory area, and own a detailed training and medical exam-

ination history (which qualifies them to perform a skill or set of skills). For example, there may be a requirement

that an operator periodically completes specific training or medical testing. Qualifications would include verifi-

cation that required training had occurred within the specified time limit. The associated skill would identify the

process capability enabled for this person through that qualification. At any given time, a Person may be assigned to

one or more factory jobs associated with other factory resources or operations.

6.3.2 The Component Information Model for Person Management is shown in Figure 2.

NamedEntity

(from Resource AIG)

TimeStamp

(from Global Type Defs)

Resource

(from Resource AIG)

Shift

(from Global Type Defs)

ResponsibilitySequence
