SEMI S10-1103 © SEMI 1996, 2003 5
AIChE
6
— Several standards covering risk assessment,
evaluation and specific topic, focused on chemical
products.
BS
7
5760–5:1991 — Reliability of systems, equipment
and components. Guide to failure modes, effects and
criticality analysis (FMEA and FMECA)
6
Available through the American Institute of Chemical Engineers, 3
Park Ave, New York, N.Y., 10016-5991, USA. http://www.aiche.org
7
Available through the British Standards institute, 389 Chiswick
High Road, London W4 4AL, United Kingdom www.bsi-global.com
SEMI S10-1103 © SEMI 1996, 2003 6
APPENDIX 1
RISK RANKING TABLES
NOTICE : The material in this appendix is an official part of SEMI S10 and was approved by full letter ballot procedures on
April 2, 2003.
NOTE A1-1: The following Tables A1-1 and A1-2 give the groups of severity and likelihood. Other examples can be found in
Related Information 3 (Risk Ranking Number) and Related Information 4 (more detailed numerical Severity and Likelihood).
Table A1-1 Severity Groups
Severity Group People (See Note A1-2.) Equipment/Facility
(See Note A1-3.)
Property
1 – Catastrophic One or more fatalities. System or facility loss. Chemical release with lasting
environmental or public health impact.
2 – Severe Disabling injury/illness. Major subsystem loss or facility
damage.
Chemical release with temporary
environmental or public health impact.
3 – Moderate Medical treatment or restricted
work activity (OSHA
recordable).
Minor subsystem loss or facility
damage.
Chemical release triggering external
reporting requirements.
4 – Minor First aid only. Non-serious equipment or
facility damage.
Chemical release requiring only routine
cleanup without reporting.
NOTE A1-2: This number is if 1-2 people are exposed to the risk. The severity group should be reconsidered to a
more severe severity group when 3 or more people are involved.
NOTE A1-3: Although it is not a safety risk it adds value to take in account product (e.g. wafers, reticles) damage.
No descriptions are given due to the fact of the value and number of products on a equipment can vary. Possible
descriptions can be: Rework of a wafer, Rework of a batch, Loss of a batch.
Table A1-2 Likelihood Groups
Likelihood Group Expected Frequency (% of Units- Year) (See Note 1.)
A – Frequent More than 1%
B – Likely More than 0.2% but not more than 1%
C – Possible More than 0.04%, but not more than 0.2%
D – Rare More than 0.02%, but not more than 0.04%
E – Unlikely Not more than 0.02%
Note 1: The frequency (in percent) is calculated by dividing the number of (observed or expected) occurrences by the number of unit-years that
the hazard has existed or is anticipated to exist, then multiplying the quotient by 100.
NOTE A1-4: If data are available, they should be used. If data are not available, the frequencies should be estimated.
NOTE A1-5: The following two example calculations are added for clarification of Table A1-2 only:
Example 1:
If something expected to happen 1 time in 5 units operated for 6 years the frequency will become:
(1 time/(5 units × 6 year of operation)) × 100% = 3.3% (= A – Frequent)
Example 2:
If something expected to happen 2 times on 50 units with 30 are operated for 6 years and 20 are operated for 7 years
the frequency will become
(2 times/(30 units × 6 year of operation + 20 units × 7 year of operation)) × 100% = 0.625% (= C – Possible)
SEMI S10-1103 © SEMI 1996, 2003 7
Table A1-3 Risk Ranking Matrix
LIKELIHOOD
RISK
RANKING
MATRIX
FREQUENT
A
LIKELY
B
POSSIBLE
C
RARE
D
UNLIKELY
E
CATASTROPHIC
1
SEVERE
2
MODERATE
3
S
E
V
E
R
I
T
Y
MINOR
4
Overall Risk Ranking Categories:
VERY HIGH HIGH MEDIUM LOW VERY
LOW
NOTE A1-6: The Risk Categories of “Very High” and “Very Low” correspond identically with the Risk Categories,
used in previous SEMI documents (e.g., S10-12-96, S2, and S14) of “Critical” and “Slight”. The terms were
changed to facilitate translation from English.
