SEMI E54.7-0999 © SEMI 19995
Table 2 Required and Optional Object Types
Object Name Seriplex Class
ID/Instance ID
(See Note 1)
CDM Tag
(See Note 2)
Required by Seriplex
(See Note 1)
Required by CDM
(See Note 2)
Required by NCS
Device
Manager
1/1 DmI0 No Yes Yes
Sensor/
Actuator/
Controller
2/1 SacI0 No Yes Yes
Assembly 3/1 through i Asm No No No
Local Link 4/1 through j Lnk No No No
Sensor – AI 33/1 through k Sai No No No
Sensor – EI 34/1 through l Sei No No No
Sensor – BI 35/1 through m Sbi No No No
Actuator – AO 36/1 through n Aao No No No
Actuator – EO 37/1 through o Aeo No No No
Actuator – BO 38/1 through p Abo No No No
Controller 39/1 through q Ca No No No
Application
Objects
129 through x/
1 through r
(See Note 3) No No No
NOTE 1: See Seriplex specification for further information; values are decimal; ‘i’, ‘j’, ‘k’, ‘l’, ‘m’, ‘n’, ‘o’, ‘p’, ‘q’ and ‘r’
represent arbitrary numbers (greater than or equal to 1) indicating that more than one instance may be supported. ‘x’ is a number
greater than or equal to 129 indicating that one or more application object classes may be supported.
NOTE 2: See CDM specification for further information.
NOTE 3: Application Dependent objects as specified in SDM.
SEMI E54.7-0999 © SEMI 1999 6
Table 3 DM Object Instance Attributes and
Services
Device Manager Object (DM)
Class ID = 01, Instance ID = 01
Attributes
ID Attribute Name CDM Tag
01 Device Type DmA1
02 Standard Revision Level DmA2
03 Device Manufacturer Identifier DmA3
04 Manufacturer Model Number DmA4
05 Software or Firmware Revision Level DmA5
06 Hardware Revision Level DmA6
07 Serial Number DmA7
08 Device Configuration DmA8
09 Device Status DmA9
12 Exception Status DmA12
13 Exception Detail Alarm DmA13
14 Exception Detail Warning DmA14
15 Visual Indicator DmA15
16 Alarm Enable DmA16
17 Warning Enable DmA17
18 Exception Detail Type DmA18
19 Exception Detail Alarm Queue DmA19
20 Exception Detail Warning Queue DmA20
Services
ID Service Name CDM Tag
01 Reset DmS1
03 Abort DmS2
05 Recover DmS3
07 Get Attribute DmS4
09 Set Attribute DmS5
11 Execute DmS6
13 Perform Diagnostics DmS7
15 Publish Attribute DmS8
17 Lock DmS9
19 Unlock DmS10
21 Get Exception Queue DmS11
23 Clear Exception Queue DmS12
7.3 Sensor, Actuator, Controller (SAC) Object –– The
SAC object is the device component responsible for
coordinating the interaction of the device with the
sensory/actuation/control environment. Each device
must support one (and only one) SAC object. The SAC
object as well as its common required and optional
attributes, services and behavior are described in the
CDM standard. The presentation of object instance
attributes and services to the Seriplex network shall be
as indicated in Table 4.
Table 4 SAC Object Instance Attributes and
Services
Sensor, Actuator, Controller Object (SAC)
Class ID = 02, Instance ID = 01
Attributes
ID Attribute Name CDM Tag
01 Last Calibration Date SacA1
02 Next Calibration Date SacA2
03 Expiration Timer SacA3
04 Expiration Warning Enable SacA4
05 Run Hours SacA5
Services
ID Service Name CDM Tag
01 Reset SacS1
03 Abort SacS2
05 Recover SacS3
07 Get Attribute SacA4
09 Set Attribute SacA5
25 Operate SacA6
27 Restore Default SacA7
29 Publish Attribute SacA8
7.3.1 Note that the format of SAC object attributes is
detailed in the CDM document; the presentation of
SAC object attributes to the Seriplex network is
detailed in Table 3 and the Seriplex standard
specification; the format of SAC object services is
detailed in the CDM document and the Seriplex
standard specification; and the presentation of the SAC
object services is detailed in Table 3 and the Seriplex
standard specification.
7.4 Assembly Object (Asm) –– The Assembly (Asm)
object instances may be used to provide for grouping
more than one attribute from one or more object
instances is a device into a single data structure for
communication over the Seriplex network. The
presentation of object instance attributes and services
shall be as indicated in Table 5.
SEMI E54.7-0999 © SEMI 19997
Table 5 Assembly Object Instance Attributes and
Services
ASSEMBLY Object (Asm)
Class ID == 03, Instance ID = 01 through i
Attributes
ID Attribute Name CDM Tag
01 Data AsmA1
Services
ID Service Name CDM Tag
07 Get Attribute AsmS4
09 Set Attribute AsmS5
7.5 Local Link Object (Lnk) –– The Local Link (Lnk)
object instances may be used to ‘link” an attribute of
one object instance to an attribute of another object
instance. The presentation of object instance attributes
and services are as indicated in Table 6.
Table 6 Local Link Object Instance Attributes and
Services
Local Link Object (Asm)
Class ID = 04, Instance ID = 01 through j
Attributes
ID Attribute Name CDM Tag
01 Source Object Class LnkA1
02 Source Object Instance LnkA2
03 Source Object Attribute LnkA3
04 Destination Object Class LnkA4
05 Destination Object Instance LnkA5
06 Destination Object Attribute LnkA6
07 Commit LnkA7
Services
ID Service Name CDM Tag
-- No services defined --
7.6 Sensor-AI Object (Sai) –– The presentation of the
Sensor Analog Input (Sensor-AI) object instance
attributes and services are as indicated in Table 7.
Table 7 Sensor-AI Object Instance Attributes and
Services
Sensor-AI
Class ID = 33, Instance ID = 01 through k
Attributes
ID Attribute Name CDM Tag
01 Name SaiA1
02 Status SaiA2
03 Alarm Enable SaiA3
04 Warning Enable SaiA5
16 Value Sai16
17 ReportInhibitTimer Sai17
18 EnableReportRate Sai18
19 ReportRate Sai19
64 Offset Sai64
65 Gain Sai65
66 DataType Sai66
67 DataUnits Sai67
68 SafeState Sai68
69 EnableReportDelta Sai69
70 ReportDelta Sai70
71 EnableReportROC Sai71
72 AlarmTripPointHigh Sai72
73 AlarmTrippointLow Sai73
74 AlarmHystersis Sai74
75 WarningTripPointHigh Sai75
76 WarningTripPointLow Sai76
77 WarningHystersis Sai77
Services
ID Service Name SDM Tag
01 Reset SaiS1
03 Abort SaiS2
05 Recover SaiS3
25 Operate SaiS4
07 GetAttribute SaiS5
09 SetAttribute SaiS6
27 RestoreDefault SaiS7
7.7 Sensor-EI Object (Sei) –– The presentation of the
Sensor Enumerated Input (Sensor-EI) object instance
attributes and services are as indicated in Table 8.
